Diesel articulated booms hiring
Z60/34
Convert units
Z60/34
| Supplier | GENIE |
| Working height | 20,30 m |
| Platform height | 18,30 m |
| Type | Z60/34 |
| Maximum outreach | 10,40 m |
| Lift capacity | 227 kg |
Platform size
 x  |
183 x 76 cm |
Length
 |
8,15 m |
Width
 |
2,41 m |
Height
 |
2,64 m |
| Weight | 10000 kg |
| Traction | 4WD |
| Power source | diesel |
Wheelbase
|
2,54 m |
Ground Clearance
|
0,30 m |
| Turning radius | 3,35/5,9 m |
| Turntable rotation | 360° |
| Drive speed | 6,44 km/h |
| Drive speed - raised | 1,1 km/h |
| Platform rotation | 180° |
| Auxiliary power unit | 12 V DC |
| Tires | 15 x 19,5 12 plis |
| Gradeability | 40% / 25% |
Data is provided as an indication and may vary depending on the year and model.
- 66 ft (20.3 m) working height
- 34 ft (10.4 m) horizontal reach
- 500 lb (227 kg) lift capacity
- Meets current emissions requirements
- Dual fuel (Gas/LPG) or diesel engine options
- Fully proportional platform controls with ramp up/down feature
- Hydraulic platform rotation
- 360° continuous turntable rotation
- Fuel select switch on platform and ground controls
- Closed-loop two speed hydrostatic drive
- Positive traction drive
- Drive enable system
- Full time 4 wheel drive (on 4WD models)
- Full time active oscillating axle
- Self-levelling platform
- Locking turntable covers
- Anti-restart engine protection
- Tilt alarm
- Horn
- Hour meter
