Diesel articulated booms hiring
800 AJ
Convert units
800 AJ
| Supplier | JLG |
| Working height | 26,40 m |
| Platform height | 24,40 m |
| Type | 800 AJ |
| Maximum outreach | 15,80 m |
| Lift capacity | 230 kg |
Platform size
 x  |
183 x 91 cm |
Length
 |
11,12 m |
Width
 |
2,44 m |
Height
 |
3 m |
| Weight | 15030 kg |
| Traction | 4WD |
| Power source | diesel |
| Turntable rotation | 360° |
| Hydraulic Platform Rotator | 180° |
| Jib (range of articulation) | 130° (+70° / -60°) |
Wheelbase
|
3,05 m |
Ground Clearance
|
0,30 m |
| Drive speed | 4,8 km/h |
| Gradeability | 30% / 45% |
| Axle oscillation | 0,20 m |
| Turning radius | 3,66 / 6,86 m |
Data is provided as an indication and may vary depending on the year and model.
- The industry’s best reach envelope
- Swing-out engine tray allows for faster and easier access for routine maintenance
- 45% gradeability and oscillating axle for improved traction
